Rs232 Keyboard

::

<top>

Converts RS232 serial to USB keyboard

HC-06 30ft Wireless Bluetooth RF Transceiver Module Serial RS232 TTL Compatiable with Arduino. Brand: HC-06 30ft Wireless Bluetooth RF Transceiver Module Serial RS232 TTL Compatiable with Arduino; Type: Assortments & Kits; Model #: HC-06-RF-Module-A; Item #.

Embedded systems no longer require expensive hand-held terminals with reduced-size keyboards. This device accepts a PS2 connector from the keyboard and provides a standard DB9 RS-232 output to connect to your asynchronous serial port at baud rates. While hardware keyboard wedges have become rare (most barcode scanners today connect via USB and appear as a human interface device ), this very flexible concept still exists in the form of a virtual keyboard wedge (a.k.a. Software keyboard wedge, “RS-232 to keyboard”-software ). These programs are usually used with devices that connect to a computer via RS-232 (COM port) or that emulate an RS-232.

</top>

Keyboard

<bottom>

For further inquiries or for volume discounts on orders larger than 25 units, please send an email to sales@intelletto.com

Rs232 Keyboard

</bottom>

HIDMDB9USBA-3E: English Keyboard, 9600 BPS , 8 Data Bits, 1 Stop Bit :HIDMDB9USBA-3E

HIDMDB9USBA-1E: English Keyboard, 38400 BPS , 8 Data Bits, 1 Stop Bit :HIDMDB9USBA-1E

HIDMDB9USBA-3D: German Keyboard,9600 BPS , 8 Data Bits, 1 Stop Bit :HIDMDB9USBA-3D

HIDMDB9USBA-1D: German Keyboard,38400 BPS , 8 Data Bits, 1 Stop Bit:HIDMDB9USBA-1D

HIDMDB9USBA-3F: French (France) Keyboard,9600 BPS , 8 Data Bits, 1 Stop Bit :HIDMDB9USBA-3F

HIDMDB9USBA-1F: French (France) Keyboard, 38400 BPS , 8 Data Bits, 1 Stop Bit :HIDMDB9USBA-1F

HIDMDB9USBA-3Q: French (Canada) Keyboard,9600 BPS , 8 Data Bits, 1 Stop Bit :HIDMDB9USBA-3Q

HIDMDB9USBA-1Q: French (Canada) Keyboard, 38400 BPS , 8 Data Bits, 1 Stop Bit :HIDMDB9USBA-1Q

HIDMDB9USBA-3EP: English Keyboard,9600 BPS , 8 Data Bits, 1 Stop Bit, USB Power to Serial PIN 9:HIDMDB9USBA-3EP

HIDMDB9USBA-1EP: English Keyboard, 38400 BPS , 8 Data Bits, 1 Stop Bit, USB Power to Serial PIN 9:HIDMDB9USBA-1EP

Rs232 keyboard

Rs232 Keyboard Arduino

HIDMDB9USBA-3DP: German Keyboard, 9600 BPS , 8 Data Bits, 1 Stop Bit, USB Power to Serial PIN 9:HIDMDB9USBA-3DP

HIDMDB9USBA-1DP: German Keyboard, 38400 BPS , 8 Data Bits, 1 Stop Bit, USB Power to Serial PIN 9:HIDMDB9USBA-1DP

HIDMDB9USBA-3FP: French (France) Keyboard, 9600 BPS , 8 Data Bits, 1 Stop Bit, USB Power to Serial PIN 9:HIDMDB9USBA-3FP

HIDMDB9USBA-1FP: French (France) Keyboard, 38400 BPS , 8 Data Bits, 1 Stop Bit, USB Power to Serial PIN 9:HIDMDB9USBA-1FP

HIDMDB9USBA-3QP: French (Canada) Keyboard, 9600 BPS , 8 Data Bits, 1 Stop Bit, USB Power to Serial PIN 9:HIDMDB9USBA-3QP

Keyboard

HIDMDB9USBA-1QP: French (Canada) Keyboard, 38400 BPS , 8 Data Bits, 1 Stop Bit, USB Power to Serial PIN 9:HIDMDB9USBA-1QP

HIDMDB9USBA-XX: User Specified Keyboard Language, Baudrate and Data Bits. Language choices are English , French (Canada), French (France), German, Czech, Italian , Hungarian and Spanish. Baudrates can be requested from 1200 BPS to 38400 BPS in steps of 1200. Data Bits choices are 7 or 8 bits. Please specify your requested settings in order instructions. You can enter order instructions after you add your choice of products to the cart, and initiate the checkout process by going to your cart. :HIDMDB9USBA-XX

HIDMDB9USBA-XXP: User Specified Keyboard Language, Baudrate and Data Bits. Language choices are English , French (Canada), French (France), German, Czech, Italian , Hungarian and Spanish. Baudrates can be requested from 1200 BPS to 38400 BPS in steps of 1200. Data Bits choices are 7 or 8 bits. USB Power to Serial PIN 9. Please specify your requested settings in order instructions. You can enter order instructions after you add your choice of products to the cart, and initiate the checkout process by going to your cart.:HIDMDB9USBA-XXP

Related Products

What is a keyboard wedge?

In the days before USB, bar code readers often came with a hardware keyboard wedge, a little device which allowed both a keyboard and the barcode reader to be connected to the keyboard port (PS/2) of a PC. Codes scanned by the barcode reader could thereby be transmitted as keystrokes. As far as the computer was concerned, there was no difference between a key pressed on the keyboard and one sent by the barcode scanner. This allowed the barcode scanner to be used with any application that accepted keyboard inputs.

While hardware keyboard wedges have become rare (most barcode scanners today connect via USB and appear as a human interface device), this very flexible concept still exists in the form of a virtual keyboard wedge (a.k.a. software keyboard wedge, “RS-232 to keyboard”-software). These programs are usually used with devices that connect to a computer via RS-232 (COM port) or that emulate an RS-232 connection while actually connecting through USB, Bluetooth SPP (serial port profile) or any other kind of virtual COM port.

Such devices include measurement instruments like balances and scales, digital calipers, etc. and legacy devices like serial barcode scanners and card readers. The software keyboard wedge connects to these devices and types received data into any application as simulated keystrokes.

Rs232 Keyboard Emulation

Keyboard wedge software for Windows

Rs232 Keyboard Emulator

This list contains all keyboard wedge programs I know of in alphabetical order. Prices were last updated on June 1st, 2019. Please leave a comment if you know a program not listed here.

  • 232key: Free (232key Plus with additional features: US$30). Easy to configure, extensive documentation available on website. Predefined settings for many balances and scales. Powerful custom regular expressions to capture exactly the data you want (Plus version only). Can be used concurrently with 232key MU (US$50) to connect to two serial devices. Disclosure: I made this.
  • Bill Redirect: Commercial (US$35). Lots of tutorials available. Particularly interesting for touchscreens.
  • Datasnip keyboard wedge: Free (AUD 10 for advanced options). Simple, straightforward user interface. Advanced options include hotkey to send command to connected device.
  • ewCaptSer: Free. Only available in German. Minimal functionality.
  • Kern Balance Connection 4: Commercial (starts at 150€ excl. VAT, includes device-specific RS-232 cable). Predefined settings for Kern balances and scales.
  • KeyInjector: Commercial (four versions from US$24.95 to US$74.95).
  • RsKey (Win CT): Free, only works with scales and balances using A&D’s data format.
  • TWedge: Commercial (from 116 US$). Extensive functionality, can be adapted to almost any task through scripts (using JavaScript).
  • WedgeLink: Commercial (89 US$ Lite, 195 US$ Standard), support up to two serial devices.
  • WinWedge: Commercial (299 US$ Standard, 399 US$ Professional). See feature list comparison.

Which keyboard wedge software is the best?

Rs232 Keyboard Wedge

Impossible to say, without knowing what you’re planning to do, looking at each program in detail and testing it to see if it works reliably.

Generally speaking (and keep in mind that I’m certainly biased here), 232key can do many things for free which would otherwise cost you money (sometimes a lot of money). It is certainly worth trying out, particularly if you want to transfer the weight from a scale or balance to your PC. Please note that 232key cannot (currently) request data from your device (by sending a device-specific command), so you’ll have to press a key on your device instead (like the “Print” key on a scale, though many scales can also be configured to send stable data automatically). Thanks to feedback from my users and customers, I’m constantly adding new useful features to 232key (see changelog).

Rs232 Serial Keyboard

TWedge is (in my experience with several demanding customers) an excellent choice if you need maximum flexibility or want to connect to multiple devices at the same time. There’s hardly anything it can’t do if you’re willing to modify the scripts that come with it. While some other programs look like they haven’t been updated in a while, TWedge is regularly improved. Its latest version can even intercept and modify data sent by USB human interface devices (HID) like modern barcode scanners.

Further information on RS-232 interfaces

Have a look at my curated page on Zeef which includes links to general information on RS-232, keyboard wedge software, terminal software and RS-232 analyzers.
